- Size: 10200*3520*3880
- Place of Origin: Qinghzou
- Brand Name: YONG DA
- Model Number: 988H
- Weight: 50000.000 kg
1. Contact us
Email: yongdamandy@gmail.com Whatsapp: 86 13583660357
Including: two forks, air-conditioner, two front tire chains; one new-updated
perforated bucket
Description | Specification | Unit | |||
Rated Power | 264 | kw | |||
Overall dimension(L x W X H) | 10200×3520×3880 | mm | |||
Operating weight | 50000 | kg | |||
Max. lifting height (Forks at level) | 2880 | mm | |||
Max. Load in Max. Lifting height | 41000/3180 | kg/mm | |||
Max. Limited Load | 49000/1800 | kg/mm | |||
Tipping load - Straight | 52000 | kg | |||
Bucket capacity | -- | m3 | |||
Dimensions of fork | (L x W x H) | 1600×350×135 | mm | ||
Load center ditance | 1000 | mm | |||
Distance of fork (Lateral) | 1740 | mm | |||
Wheel base | 4425 | mm | |||
Tread | 2650 | mm | |||
Turning angle | ±32 | ° | |||
Max.tranction force | 315 | N.m | |||
Max.Climbing Gradient | 20 | ° | |||
Turning radius | 10050 | mm | |||
Min.Ground clearance | 450 | mm | |||
Haul location height(Ground clearance of material) | 300 | mm | |||
Fuel tank capacity | 420 | L | |||
Hydraulic oil tank capacity | 380 | L | |||
Specification of tyre | Front wheel | 29.5-29-46PR | -- | ||
Rear wheel | 29.5-29-46PR | ||||
- Size: 10200*3520*3880
- Place of Origin: Qinghzou
- Brand Name: YONG DA
- Model Number: 988H
- Weight: 50000.000 kg
