- Size: 7350*2990*3240
- Place of Origin: Qinghzou
- Brand Name: YONG DA
- Model Number: 951
- Weight: 9600.000 kg
Small turning radius makes the machine flexible for operation in small working sites;
4-wheel drive ensures excellent towing performance;
Rated power | 162kw |
Overall dimensions | |
Overall length | 7350mm |
Overall width | 2990mm |
Overall height | 3240mm |
Dumping height | 3030mm |
Dumping reach | 1300mm |
Specification of tyre | 23.5-25 |
Performance parameters of entire machine | |
Operating weight | ≤ 16300kg |
Bucket capacity | 2.7 m3 |
Rated loading capacity | 5000kg |
Turning angle | ±35° |
Turning radius | 6450mm |
Gear box | YT or Sc |
Number of shifts ( forward / reverse ) | 2/1 |
Fuel tank capacity | 220L |
Hydraulic fuel tank capacity | 200L |
Lifting time | ≤ 8.3s |
Total cycling time | ≤ 13.6s |
Travel speed | |
Forward gear Ⅰ | 11.5km/h |
Forward gear Ⅱ | 38km/h |
Reverse gear Ⅰ | 16km/h |
