- Size: 5700*1950*2900
- Place of Origin: Qinghzou
- Brand Name: YONG DA
- Model Number: 920
- Weight: 1800.000 kg
Engine, torque converter and transmission are maintained easily because of being installed separately;
Instead of XJ918, XJ916;
Rated power | 50kw |
Overall dimensions | |
Overall length | 5700mm |
Overall width | 1950mm |
Overall height | 2900mm |
Dumping height | 2680mm |
Dumping reach | 1000mm |
Specification of tire | 16/17-20 |
Performance parameters of entire machine | |
Operating weight | 5.8t±5 ％ |
Bucket capacity | 1.2m3 |
Rated load | 1.8t±5 ％ |
Max. Climbing Gradient | 30° |
Rated Speed | 2400r/min |
Max. Torque | ≥206N.m |
Max. Breakout Force | 51KN |
Wheel Base | 2100mm |
Tread Width | 1490mm |
Min. Ground Clearance | ≥260mm |
Turning angle | 35°±1° |
Min. turning radius (the outer of bucket) | 4900mm |
Number of shifts ( forward / reverse ) | 2/2 |
Lifting time | ≤5s |
Total cycling time | ≤10s |
Travel speed | |
Forward gear Ⅰ | 0-9km/h |
Forward gear Ⅱ | 0-22km/h |
Reverse gear Ⅰ | 0-9km/h |
Reverse gear Ⅱ | 0-22km/h |
